Furniture hinge clips with damping 93°
Clips furniture hinge with damping 93°
HNGESYS-CLIP-ABSORB-93-ASMBYPLT-1W-CRN
Art.-no. 0683138030
EAN 4045989861781
Register now and access more than 125,000 products
Concealed Hydraulic Hinge, soft close
Quiet and controlled closing even after applying high force
Opening Angle
100˚ (93˚) Opening Angle for regular cabinet usage
Hinge cup Ø:
26 mm
Hinge cup holes distance:
38 mm
2D position adjustment:
Two dimensions of adjustment for excellent fit
Depth of hinge cup:
10.0 mm
Main material:
Cold-rolled steel
Coating:
Nickel plated
Door thickness:
12-20 mm
Clip-on system
- Clip-on system for the highest convenience
- Easy to assemble and disassemble without tools
Longevity
Industry tested standard for long life and highest reliability
Datasheets(X)
 | |
Cut depth | 10 mm |
Diameter | 26 mm |
Door position | Full overlay |
Hole distance (vertical) | 38 mm |
Material | Steel |
Opening angle | 93 Degree |
Suitable for max. door thickness | 20 mm |
Suitable for min. door thickness | 12 mm |
Surface | Nickel plated |
Type description | one way |
Type of assembly | To screw |
